| نام ویژگی | مقدار ویژگی |
|---|---|
| Inner diameter (d_mm) | 118 |
| Outer diameter (D_mm) | 80 |
| Width (B_mm) | 37.6 |
| Total width (T_mm) | 53.3 |
| Dynamic load rating (dynamic_kN) | 25.7 |
| Static load rating (static_kN) | 15.2 |
| housing_height_mm | 36 |
| housing_foot_height_mm | 12.5 |
| total_height_from_mounting_surface_mm | 53.3 |
| width_of_inner_ring_mm | 37.6 |
| overall_width_inner_ring_mm | 51.1 |
| shaft_diameter_mm | 35 |
| outer_dia_of_eccent_locking-collar_nut_of_adapter_sleeve_mm | 51.1 |
| outer_diameter_of_cover_mm | 80 |
| distance_mounting_surface_to_bearing_center_mm | 21 |
| grease_fitting | R1/8 |
| mounting_holes_distance_mm | 92 |
| housing_width_diameter_mm | 118 |
| mounting_hole_dimension_mm | 14 |
| distance_front_side_bearing_centre_mm | 18.8 |
| width_over_covers_mm | 60 |
